| Spec | Parameter |
|---|---|
| Wire reel specification： | PN800, diameter 800x diameter 400x600x diameter 80 (reel diameter x barrel diameter x outer width x aperture) |
| Load capacity： | 500kg |
| Motor and reducer for lifting： | reducer+brake K57-145.15-YEB0.37KW-M4 |
| Upper and lower limit sensors： | proximity switch SC1204-KP2 (PNP) |
| Bow level sensor： | NI8-M18-AP6X |
| Exhaust fan： | DF5 380V 0.55KW 2800/min |
| Pantograph motor： | horizontal variable frequency motor 11KW-4P fan 380V 51HZ |
| Bow driver： | well-known brands such as Huichuan/Delta/ETD |
| Twisting angle： | 1500TPM (750 RPM) |
| Take-up motor： | DC motor 130SZD-02 |
| Wire collection drivers： | well-known brands such as Huichuan/Delta/ETD |
| Wire coil clamping： | manual mode |
| Equipment center height： | 1050mm |
